State Persistence¶

Note

Burr comes with a core set of APIs that enable state persistence – the ability to save and load state automatically from a database. This enables you to launch an application, pause it, and restart where you left off. The API is customizable, and works with any database you want.

TL;DR¶

Burr provides an API to save and load state from a database. This enables you to pause and restart applications where you left off. You can implement a custom state persister or use one of the pre-built ones. You can fork state from a previous run to enable debugging/loading.

Persisting State¶

The key to writing a real life burr application is state persistence. For example, say you’re building a chat bot and you want to store the conversation history and then reload it when you restart. Or, you have a long running process/series of agents, and you want to store the state of the process after each action, and then reload it if it fails, etc….

Burr provides a few simple interfaces to do this with minimal changes. Let’s walk through a simple chatbot example as we’re explaining concepts:

Two notable assumptions:

  1. for library provided persisters, state needs to ultimately be JSON serializable. If it’s not, you can use the Serialization / Deserialization API to customize serialization and deserialization.

  2. your general assumption should be that strings are/will be encoded as UTF-8, however this is dependent on the persister you use.

State Keys¶

Burr applications are, by default, keyed on two entities:

  1. app_id - A unique identifier for the application. This is used to identify the application in the persistence layer.

  2. partition_key - An identifier for grouping (partitioning) applications

In the case of a chatbot, the app_id could be a uuid, and the partition_key could be the user’s ID or email, etc. Note that partition_key can be None if this is not relevant. A UUID is always generated for the app_id if not provided.

You set these values using the with_identifiers() method.

Note: to access app_id and partition_key in your running application, you can have the ApplicationContext injected into your Burr Actions. This is done by adding __context to the action signature:

from burr.core import action, State, ApplicationContext

@action(reads=[...], writes=[...])
def my_action(state: State, __context: ApplicationContext) -> State:
    app_id = __context.app_id
    partition_key = __context.partition_key
    ...

Initializing state¶

To initialize state from a database, you can employ the initialize_from method in the ApplicationBuilder. Important API note: unless fork_from_app_id is specified below, the values used to query for state are taken from the values provided to with_identifiers().

This action takes in an initializer (an implementation of StateInitializer) a well as:

  • resume_at_next_action – a boolean that says whether to start where you left off, or go back to the default_entrypoint.

  • default_entrypoint – the entry point to start at if resume_at_next_action is False, or no state is found

  • default_state – the default state to use if no state is found

  • fork_from_app_id – Optional. A prior app_id to fork state from. This is useful if you want to start from a previous application’s state.

  • fork_from_partition_key – Optional. The partition key to fork from. Goes with fork_from_app_id.

  • fork_from_sequence_id – Optional. The sequence_id to fork from. Goes with fork_from_app_id.

Note (1): that you cannot use this in conjunction with with_state or with_entrypoint – these are mutually exclusive. If you’re switching to use state persistence, all you need to do is remove the with_state and with_entrypoint calls and replace them with the default state and entrypoint in the initialize_from call.

Note (2): The loader will not error if no state is found, it will use the default state in this case.

Forking State¶

When loading you can also fork state from a previous application. This is useful if you want to start from a previous application’s state, but don’t want to add to it. The fork_from_app_id and fork_from_partition_key are used to identify the application to fork from, while fork_from_sequence_id is used to identify the sequence_id to use. This is useful if you want to fork from a specific point in the application, rather than the latest state. This is especially useful for debugging, or building an application that enables you to rewind state and make different choices.

When you use the fork_from_app_id to load state, the values passed to with_identifiers() will then dictate where the new application state is ultimately stored.

For a quick overview of using it, Ashis from PeanutRobotics has kindly submitted a video on how they use this feature:

Writing state¶

To write state to a database, you can use the with_state_persister method in the ApplicationBuilder. This takes in a persister (an implementation of StatePersister). It writes state to the database after each action.

An example¶

To make the above more concrete, let’s look at a basic chatbot:

state_persister =  SQLLitePersister(db_path=".sqllite.db", table_name="burr_state")
app = (
    ApplicationBuilder()
    .with_actions(
        ai_converse=ai_converse,
        human_converse=human_converse,
        terminal=burr.core.Result("chat_history"),
    )
    .with_transitions(
        ("ai_converse", "human_converse", default),
        ("human_converse", "terminal", expr("'exit' in question")),
        ("human_converse", "ai_converse", default),
    )
    .initialize_from(
        state_persister,
        resume_at_next_action=True,
        default_state={"chat_history" : []},
        default_entrypoint="human_converse
    )
    .with_state_persister(state_persister)
    .with_identifiers(app_id=app_id)
    .build()
)

In this case, we both read and write using the SQLLitePersistor. Note that this is the most common case. However, if you want to just read (E.G. for debugging), or you want to just write (if you’re always creating a new app), you can leave out initialize or with_state_persister respectively.

Supported Persistence Backends¶

See available persisters here. Note that the tracker also allows reloading from a file, but this is not recommended for production use.

Customizing State Persistence¶

Burr exposes the BaseStatePersister API for custom state persistence. Implement, pass into the above functions, and you can write to whatever database you want! Please contribute back to the community if you do so.

Loading from the Tracker¶

You can use the tracking feature additionally as a persister. This enables you to load from prior tracked runs. This is useful for debugging, or building an application that enables you to rewind state and make different choices.

tracker = LocalTrackingClient(project=project_name)
app = (
    ApplicationBuilder()
    .with_actions(
        ai_converse=ai_converse,
        human_converse=human_converse,
        terminal=burr.core.Result("chat_history"),
    )
    .with_transitions(
        ("ai_converse", "human_converse", default),
        ("human_converse", "terminal", expr("'exit' in question")),
        ("human_converse", "ai_converse", default),
    )
    .initialize_from(
        tracker,
        resume_at_next_action=True,
        default_state={"chat_history" : []},
        default_entrypoint="human_converse
    )
    .with_tracker(tracker)
    .with_identifiers(app_id=app_id)
    .build()
)

In this case the LocalTrackingClient is used both as a persister and a loader. It will persist as it is running (by tracking), and then load from the tracker if the application is restarted. This is useful for local development.

Custom Serialization and Deserialization¶

See Serialization / Deserialization for more information on how to customize state serialization and deserialization.

This includes how to register custom serializers and deserializers based on type, as well as registering custom serializers and deserializers for a field in state.
